Specifications
General Dimensions
- Wing Span: 29.79 ft
- Wing Area: 113.45 sq ft
- Length: 22.96 ft
- Height: 8.5 ft
Weight
- Empty Weight: 739 lbs with Rotax 912 ULS engine (may vary with other engines)
- Maximum Take-Off Weight (MTOW): 1,323 lbs
- Maximum Luggage Weight: 33 lbs
- Useful Load: Approximately 584 lbs, depending on fuel and configuration
Fuel Capacity
- Standard Fuel Tanks: 26 US gallons
- Optional Fuel Tanks: 34 US gallons
Engine Options
The Legend 600 can be equipped with the following Rotax four-stroke engines:
- Rotax 912 ULS: 100 hp (75 kW)
- Rotax 912 iS Sport: 100 hp (75 kW, fuel-injected)
- Rotax 914 UL Turbo: 115 hp (86 kW, turbocharged)
- Rotax 916 iS Turbo (newer option): 160 hp (119 kW, turbocharged)
Propeller Options
Various three-bladed propellers, including:
- Fixed (ground adjustable): SR 200, Bolly BOS 3, DUC Swirl 3, Helix
- Electrically adjustable: SR 3000/3BN, Neuform CR-3-V-80
- Hydraulically adjustable: KW-21 BNM
Performance (with Rotax 912 ULS, 100 hp)
- Cruise Speed: Approximately 100–108 knots
- Stall Speed: Approximately 35 knots with flaps
- Rate of Climb: 600 ft/min under standard conditions
- Range: Around 540 nm with standard 26 gal. tanks, depending on load and conditions
- Endurance: Up to 5–6 hours with standard fuel, depending on power settings
- Service Ceiling: 14,764 ft
Design Features
- Construction: Full-composite, high-wing monoplane with sandwich materials (carbon fiber and Kevlar)
- Configuration: Strut-braced, two-seat, side-by-side seating
- Landing Gear: Tricycle with steerable nosewheel; hydraulic brakes on main wheels
- Cabin: Large, comfortable cabin with spacious doors, adjustable seats, and modern avionics options
- Avionics: Customizable, ranging from basic VFR setups to advanced IFR suites (e.g., Dynon HDX, Garmin instruments
- Special Features: Amphibious float option available; suitable for glider towing
